Passenger Elevator

Audi Elevator's passenger elevator, to human nature as the height, to science and technology as a weapon, to design for the pioneer, in technology and the adoption of a new generation of permanent magnet synchronous gearless traction machine and computer control technology, the convergence of data network system and modular structure.and use the most effective self-test procedure, so that the elevator system more flexible control accurate, efficient and reasonable.

  • Technical Advantage
  • Parameters
  • Cabin Design

The safe, accurate and guaranteed position control system
Advanced sensors on the motor rotor movement for high precision real time signal feedback, to achieve in a shaft running car positioning achieve millineter level precision,achieving almost no difference level. A reliable car displacement memory technology, to ensure that the elevator open door before stopping and leveling safely function.



Earthquake protection function, high-tech life inspiration
Through emergency rapid report control operation,early detection to the seismic wave, in a timely manner to the elevator control system output alarm point, so the elevator leveling at closest floor.



Professional service at special time micro-computer group control management
Audi Elevator's group control system is a high-speed network processing central nervous system, it can calculate the building the best elevator poeration mode, the system of traffic control performance excellence from parallel "fuzzy calculation"method. The processing system is based on a highly effecient, rapid genetic algorithm, it can choose the best route for passengers to ride, so that passengers in any traffic conditions receive timely services.

Passenger elevator layout
Small machine room passenger elevator layout
SFJ-J101 Standard configurations

Celling: Middle with image roof,side of stainless steel floor with tube lamp for soft illumination design
Car walls: Center panel is made of mirror finish,hairline finish,Auxiliary panel is made of hairline finish
Floor: PVC floor

SFJ-J102

Celling: Wide arched white translucent panels lighting.
Car walls: Center panel is made of mirror finish,etching finish,hairline finish,Auxiliary panel is made of hairline finish
Handrail:6mm stainless steel short lines, arc head
Floor: PVC floor

SFJ-J103

Celling: Wide arched white translucent panels lighting.
Car walls: Mirror,etching,hairline stainless steel, Auxiliary board is hairline stainless steel
Handrail:stainless steel matte short-grain single tube
Floor: PVC floor

SFJ-J104

Celling: double arched white translucent panels lighting.
Car walls:mirror,etching,hairline stainless steel,auxiliary board is hairline stainless steel
Handrail: stainless steel matte short-grain single tube
Floor: PVC floor

SFJ-J105

Ceiling: wide arched white translucent panels lighting.
Car walls: b mirror,etching,hairline stainless steel,auxiliary board is hairline stainless steel
Handrail: stainless steel matte short-grain single tube
Floor: PVC floor

SFJ-J106

Ceiling: wide arched white translucent panels lighting.
Car walls: mirror,etching,hairline stainless steel,auxiliary board is hairline stainless steel
Handrail: stainless steel matte short-grain single tube
Floor: PVC floor

SFJ-J107

Ceiling: stainless steel mirror plate frame,video vault
Car walls: mirror,etching,hairline stainless steel
Armrest: stainless steel pipe inferior smooth short lines
Floor: PVC floor

SFJ-J108

Ceiling: stainless steel mirror hollow plates and white light board,match aluminum frame.
Car walls: central panel: mirror,etching,auxiliary panel hairline finish.
Handrail: stainless steel matte short-grain single tube
Floor: PVC floor

SFJ-J109

Ceiling: Powder spraying painted steed frame,acrylic arched lighting decoratin board(line),lamp
Car walls: imitation mahogany and stainless steel
Handrail: wood
Floor: PVC floor

SFJ-J110

Ceiling: titanium stainless steel frame,acrylic arched lighting decoration board(line)
Car walls: a combination of titanium stainless steel and etching stainless steel
Handrail: titanium
Floor: PVC floor

SFJ-J111

Ceiling: titanium stainless steel frame,acrylic arched lighting decoration board(line)
Car walls: a combination of titanium stainless steel and etching stainless steel
Handrail: wood
Floor: PVC floor

SFJ-J112

Ceiling: wooden frame, downlights, built-in light source
Car walls: mirror stainless steel, wood frame, leather hard pack
Handrail: stainless steel
Floor: PVC floor

SFJ-J113

Ceiling: steel and painted steel frame and roof,mirror stainless steel supports,downlight
Car walls: polychrome steel plate combination
Handrail: acrylic rod and titanium tube combination
Floor: PVC floor

SFJ-J114

Ceiling: titanium mirror gildiing
Car walls: titanium mirror,marble
Handrail: stainless steel round handrails
Floor: PVC floor

SFJ-J115

Ceiling: titanium stainless steel frame,titanium roof,acrylic lighting
Car walls: siding the middle of the upper glass mirror,the rest of the lower color trim titanium hairline
Handrail: ti-coated stainless steel
Floor: PVC floor
